Wedge Wire Capacities

We are a professional manufacturer of wedge wire products, we have advanced equipment, strict production principles and QC system to guarantee the product quality. Here, we will introduce our capacities of producing wedge wires to help you know our corporate strength and get a win-win cooperation opportunity.

A worker is testing the slots of wedge wire screen tubes.
  • The drawing of wedge wire cold rolling.

    Cold rolling

  • The drawing of wedge wire resistance welding.

    Resistance Welding

  • A drawing of wedge wire cutting.


  • The drawing of wedge wire rolling bend.

    Rolling bend

  • The drawing of wedge wire TIG welding.

    TIG welding

  • The drawing of wedge wire rolling.


  • The drawing of wedge wire surface treatment.

    Surface treatment

  • The drawing of wedge wire QC and package.

    QC & Package

The drawing of wedge wire cold rolling.
Cold Rolling
Cold Rolling

Cold rolling plays a crucial role in the production of wedge wire, as it allows for the creation of the unique profile that gives wedge wire its filtration and structural characteristics. We excel in the cold rolling of wedge wire. Our cutting-edge facility features state-of-the-art cold rolling machines specifically designed for creating precision wedge wire profiles. With a focus on quality and customization, we produce wedge wire products with exceptional accuracy, tailored to your unique specifications and applications.

A wedge wire cold rolling line.
Available Wedge Wire Types

We can produce profile and support wires for the wedge wire production, both standard or customized wires.

Several different shapes and sizes of profile wires and support wires produced by cold rolling.
  • Advanced Machinery. quipped with the latest generation of cold rolling machines, these machines are meticulously maintained to ensure optimal performance and consistency in the rolling process.
  • Diverse Material Compatibility. A wide range of materials, including stainless steel, carbon steel, alloys, and more to meet the unique requirements of various industries and applications
  • Custom Profile Capabilities. Whether you require wedge wire or specialized wire shapes, our experienced team can tailor the rolling process to your precise specifications
  • Precision and Tolerance Control. We employ rigorous quality assurance measures throughout the rolling process to ensure that every product meets or exceeds industry standards.
  • High Production Capacity. We can handle both small-batch and large-volume orders efficiently and deliver within tight timelines, thanks to our streamlined processes and skilled workforce
  • Quality Assurance. Our quality control team conducts thorough inspections at every stage of the cold rolling process, guaranteeing that the final product aligns with your expectations and requirements.

Cold-rolled wedge wire is the basic material of wedge wire products, including water intake screens, nozzles, filter screens, filter baskets, laterals and other products.

The drawing of wedge wire resistance welding.
Resistance Welding
Resistance Welding

At Qiusuo, we are proud to offer advanced welding capabilities in the form of resistance welding. It allows us to meet a wide range of welding needs, from high-speed production to intricate, precision work.

This continuously winding resistance welding is well-suited for joining profile wires to support wires in the construction of wedge wire screens. Continuous resistance welding ensures a secure and continuous bond between the wires, which is crucial for maintaining the structural integrity of the screen.

Resistance welding is the critical process during wedge wire production. Our advanced equipment can guarantee firm and durable welding for extended service life and outstanding performance.

A resistance welding is producing wedge wire tubes.
  • Joining Efficiency. Multiple state-of-the-art welding machines enables us to efficiently join to keep production running smoothly.
  • High-Quality Bonds. Strong and consistent welded joints guarantee the structural integrity and long-term performance of our wedge wire screens.
  • Versatility. Adaptable to various wire dimensions and materials for producing robust and dependable welds in different configurations.

Resistance welding is the necessary process during all wedge wire products production, including wedge wire screen tubes, wedge wire panels, gratings, water well screens and so on.

A drawing of wedge wire cutting

At Qiusuo, precision cutting is an integral part of our wedge wire production process. We utilize advanced cutting techniques to transform half finished wedge wires into finely crafted wedge wire screens, filters, and related components tailored to your unique specifications.

Laser Cutting

Laser cutting is a precise and versatile manufacturing process that is used in wedge wire production. It involves using a high-powered laser beam to cut through materials with a high degree of accuracy and minimal heat-affected zones. During wedge wire production, laser cutting can be applied to shape, size, or create specific patterns in wedge wire panels or tubes.

A laser cutting machine is cutting the wedge wire panel.

Shearing refers to the process of cutting or shearing wedge wire screens, panels, or tubes to specific lengths or dimensions in wedge wire production. The goal of shearing in wedge wire production is to create components with precise dimensions and clean, straight edges.

It is commonly used to cut the wedge wire cylinders or tubes into panels or cut the wedge wire panels and tubes into specific dimensions.

A shearing machine is cutting the wedge wire tube.
Laser Cutting VS Shearing
- Laser Cutting Shearing
Cutting Method Mechanical cutting thermal cutting
Precision Good precision and accuracy for straight-line cuts Exceptional precision and can create complex, detailed designs
Speed and Efficiency Relatively fast for wedge wire with uniform shapes Fast and efficient in cutting complex shapes and patterns
Edge Quality Clean, straight edges with minimal burrs Excellent and no need for secondary finishing
Complex Shapes Suit for straight cuts and basic shapes Excels at cutting complex shapes, fine details, and intricate patterns

The laser cutting machine can be used to customize special shaped wedge wire panels, cylinders and other wedge wire products. It can also be used for wedge wire tube cutting into specific dimensions.

The drawing of wedge wire rolling bend.
Rolling bend
Roll Bending

Some wedge wire cylinders, baskets or customized shaped wedge wire products are often made from wedge wire panels. To make a wedge wire basket from wedge wire panels, the panels are manipulated and assembled to form the desired basket shape. And the first step is roll bending.

Roll bending, also known as plate rolling or section bending, is a metal forming process used to bend flat or curved sections of wedge wire panels into various shapes, including cylinders, cones, and curves. In wedge wire production, roll bending is often used to shape flat wedge wire panels into cylindrical or conical forms.

A worker is operating roll bending machine to produce sieve bends
  • Versatility. create a wide range of shapes, including cylinders, cones, and curves
  • Consistency. provides consistent results across multiple pieces or batches, ensuring uniformity in the curvature of the components
  • Cost-Effective. cost-effective and particularly for large-scale production
  • Precision. Roll bending machines allow for precise control over the radius of the curved shape, ensuring that the final product meets tight dimensional tolerances.

Roll bending machine is the necessary process in wedge wire panel and sieve bends productions. Sometimes, it can be used to prepare wedge wire panel material for wedge wire cylinders or baskets.

The drawing of wedge wire TIG welding.
TIG welding
TIG welding

TIG welding (Tungsten Inert Gas welding) is a manual welding process. In TIG welding, an operator manually controls the welding torch, electrode, and filler material (if necessary) to create the weld joint, making it well-suited for applications where requires high precision and weld quality, such as welding filter baskets, flanges, or frames. Our skilled workers have years of experience to ensure precise control over the welding process and clean, precise connections in critical components.

A working is welding frames of wedge wire filter basket.
  • Precision Welding. This manual welding process is synonymous with precision and meticulous attention to detail, allowing us to craft clean, aesthetically pleasing, and high-quality welds.
  • Customization. We can tailor the welding parameters to meet specific requirements, ensuring the highest level of accuracy and weld integrity
  • Diverse Material Compatibility. Compatible with various materials, including SS, aluminum, and alloys to satisfy different industries needs

TIG welding is commonly used in the post production, where there needs to add flanges, frames and other accessories on wedge wire screens. Besides, it is an essential process for wedge wire screens tubes which in FITO (From Inside To Outside) types.

The drawing of wedge wire rolling.

Wedge wire cylinder rounding is necessary when the cylinder roundness can not meet dimensional specifications. The cylinder is fed between the rollers, which are adjusted to apply pressure to the non-round areas. The cylinder is incrementally rolled to achieve the desired roundness.

A rolling equipment is rolling wedge wire screen cylinder.
  • Guarantee the dimensional accuracy and operation efficiency of wedge wire cylinders.
  • It can ensure the maintaining consistency, improve cleanliness and make it ease of cleaning.

Rolling process is necessary for wedge wire cylinder, wedge wire basket and rotary drum screens production.

The drawing of wedge wire surface treatment.
Surface treatment
Surface treatment

In wedge wire production, we adopt pickling and electroplating surface treatment method. The whole process are typically performed in a controlled environment to ensure consistent result and compliance with industry standard. These finishes contribute to the overall quality and performance of the wedge wire product, ensuring it meets the required standards for corrosion resistance, cleanliness, and aesthetics.


Pickling is a chemical process used to remove surface impurities, scales, oxides, and contaminants from the stainless steel surface. The primary goal is to prepare the material for subsequent treatments and improve its corrosion resistance.

Immersing the stainless steel wedge wire product in a chemical bath typically composed of an acid solution, such as nitric or hydrofluoric acid. The acid reacts with the impurities on the surface, dissolving them and leaving behind a clean, passive surface.

  • Removal of scale, rust, and impurities.
  • Create a clean and uniform surface.
  • Enhanced corrosion resistance by promoting the formation of a passive oxide layer.
  • Improved adhesion of subsequent coatings or treatments.

Electropolishing is an electrochemical process used to further improve the surface finish and corrosion resistance of stainless steel wedge wire products. It removes a precise and controlled layer of material from the surface.

During electropolishing, the wedge wire product is submerged in an electrolyte bath, and an electrical current is applied. This causes the dissolution of surface irregularities and the removal of a thin layer of material. The process is highly controllable, resulting in a smooth and bright finish.

  • Create a highly reflective and ultra-smooth surface finish.
  • Remove microscopic surface defects.
  • Enhance corrosion resistance performance by promoting the formation of a passive oxide layer.
  • Improve cleanability and resistance to contamination.

Surface treatment is the necessary for almost all wedge wire products to provide extended service life in complex working conditions.

The drawing of wedge wire QC and package.
QC & Package
Quality control and packaging

To ensure that our customers receive only high-performance and qualified products, all goods will undergo stringent testing as part of our strict quality control system.

Besides, we will adopt varied packaging materials and methods based on the range of our wedge wire products, with the aim of providing the maximum protection during long-distance transportation.

Wedge wire tube length measuring

Wedge wire tube diameter measuring

Wedge wire tube slot size measuring

Wedge wire intake screen plastic bubble film package

Wedge wire screen tubes in plastic net sleeves package

Wedge wire filter nozzles plastic bag package
